180 XT MAX Awning
$1,495.00 Exc. Freight & TaxesThe 180 XT MAX™ Awning is the ultimate solution as a free standing shade awning in terms of massive shade coverage (8.53m2 / 91.82ft2), wind resistance, and shares the same strength and durability as our famous 270 XT Awning and 270 XT MAX Awning.
The 180 XT MAX™ Awning is 90.5 inches long (2.3m) when packed up weighs only 57.3lbs (26Kg) and can be easily mounted to most roof racks or heavy duty load bars using our Heavy Duty L Brackets (included with the awning) or to our Roof Top Tents using the appropriate awning to tent bracket (sold separately).
Around the inside edge of the awning is a 50mm / 2″ thick triple stitched velcro strip which can be used to attach the optional awning walls (sold separately) enabling you to fully enclose the area to provide protection from the elements or additional privacy.
Fitting the 180 XT MAX™ Awning
The 180 XT MAX™ Awning frame requires a fitment bracket attached to the stainless steel sections no more than 200mm / 7 ⁷/₈inch from each end. The awning is not suitable to be fitted to a roof rack shorter than 1.9m / 74.8inches in length or to load bars where the width from front to rear is less than 1.9m / 74.8inches. When using our Heavy Duty L Brackets (supplied with the awning) for mounting the 180 XT MAX™ awning, we recommend using one pair of the brackets, with one at each end.
-
180 XT MAX Awning Wall Kit
$1,150.00 Exc. Freight & TaxesThe 180 XT MAX Awning Wall Kit is the perfect solution if you want more privacy & protection from the elements for your 180 XT MAX Awning set-up,
The 180 XT MAX Awning Wall Kit comes as a complete kit with 3 main walls and a fourth that can be used to screen off either the front or rear arm area.
The kit comes wth 4 aluminium telescopic poles.
-
270 XT Awning Mk2
$1,495.00 Exc. Freight & TaxesThe 270 XT Awning Mk2 sets new benchmarks for a free standing shade awning in terms of overall strength, wind resistance and durability. The 270 XT Awning Mk2 provides an incredible 8sqm (86sqft) of shade around your 4WD for you to set up your camp kitchen, swags or just a shaded seating/chill out area.
The awning is 2.3m / 90.5 inches in length, weighs only 27.8Kg / 61.3lbs and can easily be set up by one person in about 30 seconds and the pack down is just as simple.
The awning is available in either a Left Hand Side (driver’s side in USA) or Right Hand Side (passenger side in USA) configuration, please select which version you require from the drop down menu below.
There are 2 Heavy Duty L brackets supplied with the 270 XT Awning Mk2. One fitment bracket must be attached to the stainless steel head stock at the hinged end of the awning no more than 200mm (7 ⁷/₈inch) from the hinged end, The second bracket must be mounted no less than 1.3m (4′ 3″) from the bracket at the hinged end. To mount the awning to one of our rooftop tents you will need an Awning To Tent bracket which are sold separately.
-
270 XT Awning Wall Kit
$1,150.00 Exc. Freight & TaxesIf you’re looking to enhance privacy and shield yourself from the elements with your 270 XT Awning set-up, the ideal solution is the 270 XT Awning Wall Kit. This kit includes 4 main walls and 5 aluminium telescopic poles that conveniently fit into pre-drilled holes in the trussed awning arms, offering added stability and support for the walls.
Check out the full product review video to see the kit in action and the product description below for more details.
-
270 XT MAX Awning Mk2
$1,850.00 Exc. Freight & TaxesThe 270 XT MAX Awning Mk2 sets a new standard for a free standing shade awning with massive shade coverage (+/-12m2 / 129ft2), great wind resistance and shares the same strength and durability as the famous 270 XT Awning.
The 270 XT MAX Awning Mk2 is 2.3m (7’6″) long when packed away, weighs only 33.5Kg (74lbs) and can set up or packed away by one person in under 60 seconds.
The awning is available in either a Left Hand Side (driver’s side in USA) or Right Hand Side (passenger side in USA) configuration, please select which version you require from the drop down menu below.
The 270 XT MAX Awning Mk2 requires a fitment bracket attached to the stainless steel head stock at each end of the awning frame no more than 200mm (7 ⁷/₈inch) from each end, there are 3 Heavy Duty L brackets supplied with the awning. The awning is not suitable to be fitted to a roof rack shorter than 1.9m (75″) in length or to load bars where the width from front to rear is less than 1.9m (75″). We recommend having a third bracket positioned in the middle of the awning.
To mount the awning to one of our rooftop tents you will need an Awning To Tent bracket which are sold separately.
-
270 XT MAX Awning Wall Kit
$1,250.00 Exc. Freight & TaxesIf you’re looking to enhance privacy and shield yourself from the elements with your 270 XT MAX Awning set-up, the ideal solution is the 270 XT MAX Awning Wall Kit. This kit includes 5 main walls and an additional 6th wall, which can be used to create a partition in either the front arm area or beneath the awning. The kit also provides six aluminium telescopic poles that conveniently fit into pre-drilled holes in the trussed awning arms, offering added stability and support for the walls.
Check out the full product review video to see the kit in action and the product description below for more details.
-
Awning Bag Replacement
$200.00 Exc. Freight & TaxesIf you have damaged your Navigator Outdoor awning bag don’t panic! We have Awning Bag Replacement for all of our awnings.
Navigator Outdoor awning bags are 460gsm (16.2oz) poly-cotton rip-stop canvas with YKK Zippers. In contrast to PVC covers, the canvas allows the awning to breath while keeping it dust/dirt free and moisture is able to wick out through the zipper reducing the risk of mould or mildew.
The rip-stop material on the bag also reduces the risk of large running tears in the bag as a result of contact with tree branches, and the front and rear sections of the bag have a double layer of canvas providing extra protection.
Select which awning bag you need from the drown list.
-
Awning Brackets / Awnings & Accessories / Rooftop Tent Accessories & Brackets / Rooftop Tents & Accessories
Awning To Tent Bracket 4 Piece – LX27
$159.00 Exc. Freight & TaxesThe Awning To Tent Bracket 4 Piece is designed to be easily mounted to The Bush Company’s LX27 Clamshell Rooftop Tent by using the ‘Ezi Slot’ channels in the base frame of the tent.
The Awning To Tent Bracket 4 Piece is universal so can be mounted to the left or right side of the tent. For 270 awnings such as The Bush Company’s 270 XT™ Awning and especially the 270 XT MAX™ Awning it is important that the awning bracket can support the weight of the awning in off-road conditions, but can also cope with the twisting motion of the awning on its hinge when in use.
NOTE: if you need to mount the awning bracket pointing upwards due to your vehicle configuration, we recommend selecting the Spring Road Adapter with the awning bracket. The Spring Rod Adapter eliminates the need to bend a ‘dog leg’ in the spring steel pole of your tent to clear the awning when deployed. The Awning To Tent Bracket 4 Piece is only suitable for the LX27 rooftop tent.
-
Classic Awning Bracket
$145.00 Exc. Freight & TaxesThe Classic Awning Bracket is designed to hold your awning off from the side of the tent to clear the gas struts on the tent. This bracket is intended for mounting awnings to Navigator Outdoor Classic Series tents, but can also be used to mount shower tents to Navigator Outdoor Tents such as the AX27, DX27 and TX27.
The Classic Awning Bracket is constructed from stainless steel with a black powder coated finish and is supplied with stainless steel bolts and nyloc nuts required for fitment.
-
Ladder Plate assembly – mounts to ladder – 2 Bolts for ladder
$35.00 Exc. Freight & TaxesThe Ladder Mount Plate is designed to mount to your ladder to enable it to be attached the ladder mounting bracket on Navigator Outdoor rooftop tents. There are two variants for this mount:
- Double Bolt Ladder Mount Plate – this is the latest version of Navigator Outdoor ladder mount styles, helps to prevent the ladder from rocking side to side.
The Ladder Mount Bracket is made from stainless steel in a powder coat black finish to match the rooftop tents.
NOTE: the ladder mount bracket that mounts to the tent is sold separately here or you can use the wide ladder mount bracket available here
-
Spring Rod Adapter
$32.00 Exc. Freight & TaxesThe Spring Rod Adapter mounts to the Navigator Outdoor’s Tent To Awning Bracket for tents that have that have the ‘Ezi-Slot’ channels built into the frame. Spring Rod Adapter bracket only required if the tent to awning bracket is mounted pointing upwards – usually done to avoid the vehicle doors from rubbing on the awning bag.
The Spring Rod Adapter is made from stainless steel in a powder coat black finish to match the rooftop tents. The bracket is supplied with stainless steel M8 pan head bolts and nyloc nuts and comprehensive fitting instructions.
The adapter is available in a left and right hand version.
-
Strap Hook Bracket
$18.00 Exc. Freight & TaxesThe Strap Hook Bracket is designed to mount to the side of Navigator Outdoor rooftop tents that have ezi-slot channels in the side of the frame. The bracket provides a low profile, convenient point to attach awning straps when deploying your awning.
The Strap Hook Bracket is made from stainless steel in a powder coat black finish to match the rooftop tents. The bracket is supplied with stainless steel M8 pan head bolts and nyloc nuts and comprehensive fitting instructions.
-
Tent To Awning Bracket
$168.00 Exc. Freight & TaxesThe Tent To Awning Bracket is designed for Navigator Outdoor’s rooftop tents that have the ‘Ezi Slot’ channels in the frame of the tent such as the AX27, DX27, TX27 and TX27 MAX. This bracket provides the support necessary to withstand the forces generated by free standing awnings.
The Tent To Awning Bracket is universal so can mounted to the left or right hand side of the tent.
IMPORTANT: the Tent To Awning Bracket can be mounted with the brackets pointing upwards or downwards. If you need to mount the awning bracket pointing upwards due to your vehicle configuration, you should also purchase the Spring Road Adapter with the awning bracket as this prevents possible damage to the awning as a result of contact with the spring steel pole for the rainfly of your tent.
You can view the video of how to install the Awning Bracket here.
-
Universal Single Canvas Wall Kit
$299.00 Exc. Freight & TaxesIf you are in need of extra shade, privacy, or protection from the elements for any of Navigator Outdoor’s awnings, you have to consider the Universal Single Canvas Wall Kit.
This wall has a universal design with a width of 2.3m/7’7″ and a maximum height of 2.4m/7’10”. It is made from 260gsm rip stop canvas with a sturdy 600gsm PVC splash skirt with adjustable eyelets, which can be secured using the included pegs. Additionally, the kit includes two aluminium telescopic poles that attach to the awning arms to provide extra support when the wall is in use. The wall has quality zippers on both sides, enabling you to join multiple walls together if desired. To protect your vehicle, there are zip-on sections on each side that prevent the zipper from scratching your car’s surface.
The wall itself weighs 3.4Kg/7lbs 8oz, while the total weight, including the poles and pegs, is 5.4Kg/11lbs 10oz.
-
Wide Ladder Mount Bracket
The Wide Ladder Mount Bracket is designed to mount to the side of Navigator Outdoor rooftop tents that have ezi-slot channels in the side of the frame. The bracket spaces the receiver for the telescopic ladder 70mm from the side of the tent.
