Description
Key Features:
- Compact size
- Easy install
- Lock-in and lock-out safety system
- Stainless steel and blue anodised aluminium fittings
- Powder-coated steel frame construction
- Travel lock and key
- Anodised blue faceplate
Note:
5 sizes available to suit a variety of applications, click here to view size compatibility chart. MSA 4X4 Fridge Barriers available for all models.
| Weight | 82lbs / 40kg | ![]() |
| Freight Dimensions | 980×690×170 | |
| Fridge Tray1 | 810×480 | |
| Slide Length Closed2 | 880+20 | |
| Slide Length Open3 | 1860+20 | |
| Overall Width4 | 590+20 | |
| Handle Width5 | 535 | |
| Drop6 | 300 | |
| Mount to Base | 35 | |
| Max Set Back | 120 | |
| Gas Strut | 800N | |
| (all measurements displayed are in mm) | ||
